HELIUS is the first in the series of ARUN’s XRF handheld spectrometers. Using X-ray fluorescence analysis technology, this mid-size instrument analyses products of various materials quickly, reliably, and non-destructively. Weighing 1.51 Kg; this is the lightest amongst other devices in the market.
Inside the brochure is all the information you need about the HELIUS XRF’s that we have to offer, including the 300, 600 and 900.
HELIUS 300 – This is the go-to instrument for getting grade identification of metals in seconds without extensive analysis.
HELIUS 600 – This is the ideal instrument for scrap metals sorting and positive materials identification.
HELIUS 900 – This is the best analyser for environmental and RoHS compliance screening and geological inspections.
Since the introduction of XRF spectrometry in the 1950s, it has been a proven and popular technique for metal analysis and is widely used as an efficient means in quality control for many metal processing facilities.
The HELIUS XRF series of metal analysers are a good choice for analysis in many fields; delivering rapid and accurate results right in the palm of your hand. Due to the advanced electronics and state-of-the-art mathematical algorithms, the HELIUS XRF instruments provide ultimate quality of measurement within a couple of seconds. It is the ideal solution for checking and analysing incoming materials, finished goods and in-process production parts in a non-destructive way.
The HELIUS (XRF) is available in 3 models: 300, 600 and 900. All have an excite source of 50KV/4W Ag Anode, max. 80uA x-ray tube.
HELIUS 300 and 600 are calibrated for either alloys (Cast), precious metals (Kt) or minerals (Geo). The HELIUS 300 and 600 (Cast) models are calibrated for Fe, Cu, Ni and Ti. If other bases are required for precious metals or minerals, this can be configured.
The HELIUS 900 is calibrated for either alloys (Cast) or minerals (Geo). The HELIUS 900 (Cast) model include Mg, Al, Si, P, and S light elements and Al-based alloys.
HELIUS 300 Cast|Kt|Geo
This low-end version XRF has an Si-Pin detector with no light element detection. This is a good instrument for getting grade identification of metals in seconds without extensive analysis. With its simple pass/fail sorting mode, this is ideal for the quick incoming inspection of materials. | HELIUS 600 Cast|Kt|Geo
This mid-range version has a built-in top end SDD detector. It provides reliable results in as little as 2 seconds for most alloys. It is the ideal instrument for scrap metals sorting and positive materials identification. | HELIUS 900 Cast|Geo
This high-end version with SDD technology provides reliable results
of non-metallic materials in seconds. It is the ideal analyser for environmental and RoHS compliance screening and geological inspections. |
Anytime
ANYWHERE
The ergonomic design, light weight and small size are a good balance in the hand. The tapered test head can easily detect curved or corner parts, such as welds. The large capacity battery ensures work can be carried out for as long as 10-12 hours.
- The 5.5” colour touch screen with backlight function will allow the user to see the screen in sun-lit conditions. Touch screen gloves can be worn while manoeuvring through the screen functions.
- It has the most comprehensive grade library which includes AISI, DIN, JIS and GB grades, covering more than 1,600 alloys. The user can modify the existing grade library, add new grades or customise the library.
- Up to 100,000 test results of storage space, including spectrograms and sample images.
- Results and reporting data can easily be transmitted over to PC by Wifi.
- An optional sample camera function is available for accurate test positioning.
